Nidaplast panels are honeycomb structures, 8mm mesh, made of polypropylene used as the core of structural sandwich panels. These are polymeric, thermoplastic materials. You also have the choice between finished panels, rigid panels.
The Nidaplast 8 product has the “Certificate of Naval Approval” issued by DNV. Germanischer Lloyd certificate.
The polyester nonwoven on nidaplast 8 offers an ideal surface for impregnation with thermosetting resins (polyester, epoxy, etc.).
The thermo-welding of this nonwoven on the honeycomb structure ensures it a perfect grip.
Finally, the plastic film placed under the nonwoven makes the cells airtight and limits the consumption of resin.
The polypropylene honeycomb structure composed of 95% vacuum uses little material while ensuring high mechanical properties.
The honeycomb is made of polypropylene, a durable and 100% recyclable material. Manufactured on our industrial site in France.
- Large panel dimensions: 2500 x 1220 mm
- Different thicknesses: from 5 to 100 mm
- Cell size: 8 mm
- Indicative surface mass for a 20 mm panel: 1.5 kg / m2
